7106274 Cat Pump 4DNX25GSI with Mounting Plate and Hardware
In stock
Part Number
7106274
$329.90
The 7106274 Pump is the Cat Pump 4DNX25GSI with mounting plate and hardware.
This cat Pumps triplex (three plunger rods) positive displacement, reciprocating plunger pump is constructed with a brass manifold, 304 stainless steel valve assemblies, solid ceramic plungers and standard NBR (Buna-N) seals and O-rings.
4DNX Series pumps are hollow-shafted and designed to bolt directly to a gas engine with a 3/4" straight horizontal shaft, providing an easy, compact installation.
Technical Specifications
| Max Flow | 2.5 gpm / 9.5 lpm |
| Max Pressure | 3000 |
| Inlet Port Size | 3/4" GH(F) |
| Discharge Port Size | 3/8" NPT(M) |
| RPM | 3450 |
| Drive Type(s) | Direct |
| Material | Brass |
