M22456-1 ROTOR KIT 1/2 WITH VANES AND INSERT
In stock
Part Number
M22456-1
$22.29
The M22456-1 Carbon Rotor is the main part of the air pump for your portable kerosene or diesel fired heater.
This M22456-1 Carbon Rotor fits inside the pump ring body on the back of the motor and with the carbon blades and plastic insert makes up the components of the air pump for your portable kerosene heater.
The M22456-1 Carbon Rotor can be purchased as a complete kit which will include the 1 of parts number M22456-1 Carbon Rotor, 4 of part number M8643 1/2 Carbon Blade vane and 1 of part number M22009 Plastic Insert. The can be ordered under part number PP204.
The M22456-1 rotor is driven directly by the motor and is attached to the motor shaft by means of a plastic insert. As the motor rotates, the carbon blades travel outward rubbing against the inside surface of the steel pump body.
The rotor's position inside the pump body is such that it is not concentric with the pump body and a .003/.004 of an inch gap is set at the uppermost quadrant.
As the motor rotates, the air between the blades is compressed and routed to the nozzle through the air line.
The carbon rotor blades will wear out after time and cause the output filter to fill with carbon particles.
Replacement of the output filter and carbon blades should be done on a regular basis.
This M22456-1 Carbon Rotor fits inside the pump ring body on the back of the motor and with the carbon blades and plastic insert makes up the components of the air pump for your portable kerosene heater.
The M22456-1 Carbon Rotor can be purchased as a complete kit which will include the 1 of parts number M22456-1 Carbon Rotor, 4 of part number M8643 1/2 Carbon Blade vane and 1 of part number M22009 Plastic Insert. The can be ordered under part number PP204.
The M22456-1 rotor is driven directly by the motor and is attached to the motor shaft by means of a plastic insert. As the motor rotates, the carbon blades travel outward rubbing against the inside surface of the steel pump body.
The rotor's position inside the pump body is such that it is not concentric with the pump body and a .003/.004 of an inch gap is set at the uppermost quadrant.
As the motor rotates, the air between the blades is compressed and routed to the nozzle through the air line.
The carbon rotor blades will wear out after time and cause the output filter to fill with carbon particles.
Replacement of the output filter and carbon blades should be done on a regular basis.
The M22456-1 Carbon Rotor fits the following models:
Reddy Heater:
AC-165
R100
R100A
R100B
R110
R110BT
R110C
R110M3
R115
R115T
R150B
R150BT
R150D
R150E
R150M
R150M2
R155
R155A
R155B
R165
R165A
R165AT
R165T
R200
R200A
R200AT
R200BT
RE200T
Master Heater:
B30
B30C
B50
B50A
B50B
B50D
B50E
B50F
B50G
B50H
B50J
B55
B55T
B55CT
B60
B65
B65D
B66D
B70
B70B
B70BT
B70D
B70DT
B70ET
B99D
B100
B100A
B100AAK
B100B
B100C
B100D
B100E
B100F
B100G
B100KG
B110
B110A
B110B
B110BT
B110T
B115
B115CT
B115DT
B115T
B120
B125C
B140
B140D
B150
B150A
B150B
B150C
B150CAK
B150D
B150F
B150FT
B150G
B150GT
B150H
B150J
B150JT
B150JT
B150KD
B150M
B155A
B155B
B155C
B155CT
B155DT
B155T
B165
B165A
B165AT
B165T
B165CT
B165DT
B200
B200AT
B200BT
B200T
Remington:
REM100
REM100A
REM110
REM110A
REM110B
REM11OBT
REM115
REM115T
REM150A
REM150B
REM150D
REM150E
REM155
REM155A
REM155B
REM165
REM200
REM200AT
REM200T
RH200VT
RHD200VT
RM115
RM155
RM20AT
RM200T
All-Pro Universal:
PKC70ET
PKC115DT
PKC165DT
DESA, Knipco and Koehring:
C35
C35A
C35B
C50D
C50E
C50F
C100D
C100E
C100F
C150D
C150E
C150F
F30
F50
F50A
F50D
F50E
F50F
F50G
F50S
F65
F65D
F66
F66D
F110
F110D
F110E
F110F
F110G
F110H
F120
F140
F150
F150D
F150E
F150F
F150G
F10H
F150S
K30
K50
K50A
K100
K100A and many other older Desa International portable heaters.
Reddy Heater:
AC-165
R100
R100A
R100B
R110
R110BT
R110C
R110M3
R115
R115T
R150B
R150BT
R150D
R150E
R150M
R150M2
R155
R155A
R155B
R165
R165A
R165AT
R165T
R200
R200A
R200AT
R200BT
RE200T
Master Heater:
B30
B30C
B50
B50A
B50B
B50D
B50E
B50F
B50G
B50H
B50J
B55
B55T
B55CT
B60
B65
B65D
B66D
B70
B70B
B70BT
B70D
B70DT
B70ET
B99D
B100
B100A
B100AAK
B100B
B100C
B100D
B100E
B100F
B100G
B100KG
B110
B110A
B110B
B110BT
B110T
B115
B115CT
B115DT
B115T
B120
B125C
B140
B140D
B150
B150A
B150B
B150C
B150CAK
B150D
B150F
B150FT
B150G
B150GT
B150H
B150J
B150JT
B150JT
B150KD
B150M
B155A
B155B
B155C
B155CT
B155DT
B155T
B165
B165A
B165AT
B165T
B165CT
B165DT
B200
B200AT
B200BT
B200T
Remington:
REM100
REM100A
REM110
REM110A
REM110B
REM11OBT
REM115
REM115T
REM150A
REM150B
REM150D
REM150E
REM155
REM155A
REM155B
REM165
REM200
REM200AT
REM200T
RH200VT
RHD200VT
RM115
RM155
RM20AT
RM200T
All-Pro Universal:
PKC70ET
PKC115DT
PKC165DT
DESA, Knipco and Koehring:
C35
C35A
C35B
C50D
C50E
C50F
C100D
C100E
C100F
C150D
C150E
C150F
F30
F50
F50A
F50D
F50E
F50F
F50G
F50S
F65
F65D
F66
F66D
F110
F110D
F110E
F110F
F110G
F110H
F120
F140
F150
F150D
F150E
F150F
F150G
F10H
F150S
K30
K50
K50A
K100
K100A and many other older Desa International portable heaters.
