0034819.01 Blue Teapo Capacitor for Coleman Generators

0034819.01 Teapo Capacitor has the following ratings 220uF 200V.HD 85/C and fits various Coleman Powermate PM Series Generators.

The 0034819.01 Capacitor has been changed from the original 130uF to 220uF to help increase the life of the capacitor, the voltage and heat range of the capacitor have remained the same
This capacitor works the same in all aspects of the older version, and with the 220uF, it will increase the ability of the capacitor to remain charged.

The 0034819.01 Capacitor may need to be soldered into the end bell wire housing assembly on older units.

This 0034819.01 Capacitor is also used on some Pramac, Onan, Honda, and Yamaha generators as well as other privately labeled generators.

This same 0034819.01 Capacitor was also used by Kawasaki for their generators, which were made by Pramac.

Size for this item is as follows:

The body of the capacitor is 2 inches long, and the width is 1 inch across with standard 1/4 spade connectors.

SERVICE NOTE:

The negative terminal will be stamped with a crosshatch pattern on the top the capacitor terminal.
