7115203 Idle Down Valve and Cable Replacement Kit with Bolts

Out Of Stock

Part Number

7115203

$57.78

Part Number: 7115203

Brand: AAA, OEM, DeWalt, Simpson, Delco

Shipping Weight: 1 Lbs

Documents:

View 7115203 Idle Valve Installation Instructions

This item is NOT currently in stock and will be shipped as soon as possible. Typical lead times are 5-10 business days for common stock items that are pictured and 15-25 business days for non stock and special orders. Please email customer service for specific details if required at
customerservice@allpartsinc.com

Qty

The 7115203 Idle Down valve and cable replacement kit is the complete engine throttle cable with attached idle down valve and mounting bolts for the FNA Group brands of pressure washers using this type of automatic idle control.

This 7115203 is used with the 510032 and 51ALD23 Vertical Axial pumps with the Push Idle control system.

This automatic Idle Control system was used on the following models of pressure washers:

DeWalt DXPW3224I Pressure Washer Item Number 61109

Take great care in the tightening of the Banjo Bolt on these kits.

A Torque Wrench and a Digital Tachometer will be required for proper installation.

Over tightening of the mounting bolt will result in the bolt breaking.

The banjo bolt manufacturer's maximum torque recommendation is 7-8 Ft lbs. / 88-96 In Lbs. / 10-11 N-M
Valve cap torque: 13 Ft lbs. / 159 In Lbs. / 18 N-M
Cable retention bolt torque: 7.3 Ft lbs. / 87.6 In Lbs. / 9.9 N-M

See Included Instructions or download from this listing as PDF Document.
