6003-NAT Dexen Natural Gas Millivolt Valve - Fixed Flame Height Muti-Port Universal Fit

The Dexen 6003 NAT Gas valve is an OEM CSA-certified and tested replacement millivolt-operated thermopile only gas valve configured for use with natural gas

This OEM replacement gas valve has the following specifications.


Models: 6003 NAT Description: Dexen Gas valve mV valve with quick drop-out safety magnet Gas Type: NG Pressure Setting Range Fixed: 3.5” w.c Natural Gas Range of regulation: 5,000 – 70,000 Btu/hr Ambient Temperature Range: -40°F to 175°F Control Type: On/Off Millivolt Manual Adjustment Valve Inlet Size: 3/8” & ½” NPT Outlet Size: 3/8” & ½ NPT Side Taps: 3/8” & ½” NPT Pilot: 7/16”-24 UNS

Mounting Holes: 3/16”-24 UNS

Mounting Position: Any For Use with Thermopile Only Adjustable pilot flow Pneumatically inline

• Replacement For: EQUIVALENT TO HEATILATOR 060-500, AMERICAN HEARTH R8380, CONTINENTAL G-522A, WS725-13, EMPIRE COMFORT SYSTEMS: R8380, HEAT-N-GLO 060-500, 060-500
• Replacement For: HPC FIRE 200 CONTROL VALVE, 200 MVLRC-N NATURAL GAS VALVE, LENNOX: H2299, H4260, 9737, LEXINGTON FORGE 75-29-109, 7529109, 75-29-109, 7529109
• Replacement For: MAJESTIC/ INSTA-FLAME / MAJCO 75-29-109, 7529109, 75-29-109, 7529109, MONESSEN 75-29-109, 7529109, MONTIGO/CANADIAN HEATING RGC1011, RGC1011
• Replacement For: NAPOLEON G-522A, WS725-13, QUADRAFIRE 060-500, 060-500, RH PETERSON/REAL FYRE SV6, IHP 009737, H2299, H4260, 9737

Cross reference:
Robertshaw 710-502
Robert Shaw RS710-502
