5170044-13 DeWalt 3600 PSI Replacement Pump with Adjustable Unloader

5170044-13 DeWalt 3600 PSI 2.5 GPM replacement Triplex Plunger Pump is a highly efficient pump that minimizes engine load while delivering top performance

This DeWalt Replacement Triplex Plunger Pump is equipped with a patented PowerBoost technology that provides higher pressure at the spray nozzle.

This 5170044-13 pump also contains dual oversized ball bearings for better wear, friction resistance, and longer-lasting performance in tough cleaning environments.

Features:

3600 PSI @ 2.5 GPM


PowerBoost Technology
Fully adjustable unloader system with ergonomic control
Sight glass and advanced oil seal technology does away with the need for a dipstick
Thermal relief protection to prevent pump overheating
Dual oversized radial ball bearings are installed for better wear, friction resistance, and precision ceramic coated pistons for extended seal life
Crankcase is manufactured from fully anodized die-cast aluminum for corrosion protection and is sealed to prevent contamination and lube failure
Gas engine flange and hollow shaft that fits most horizontal shaft engines

Specifications:

PSI: 3600 Max
GPM: 2.5

Inlet Port: 3/4" GH
Discharge Port: Threaded male fitting
Inlet Pressure Range: 10-60 PSI
Thermal Relief Port: 1/4" NPT
Shaft Diameter: 3/4"
Flange Bolt Pattern: SAE J-609A
Key Way: 3/16"
Pump Oil Capacity: 8.0 fl oz.
PowerBoost®: Yes
Head: Forged Brass
