510001 Pump Assembly Round Base 2500 PSI 2.0 GPM from OEM Technologies

The 510001 Pump assembly includes the garden hose inlet fitting, inlet filter screen, M22 outlet fitting, and thermal relief valve.

The 510001 OEM Technologies pump is an oil-filled Direct-Drive Axial Cam pump used in various pressure washers using a 22MM High Pressure Hose connection.

This OEM Technologies industry-leading vertical mounting pump with a 7/8 shaft and has a universal round base mounting flange allowing multiple-direction mounting and is rated for 2500 PSI at a flow rate of 2.0 GPM Max PSI

Features of the 510001 Axial Cam Pump from OEM Technologies

• High-pressure pump rated for 2500 PSI @ 2.0 GPM
• Multi-point round base vertical mounting flange
• OEM Technologies advanced manifold design helps keeps the water pressure strong
• Included thermal relief valve protects against overheating
• Corrosion-protected aluminum crankcase reduces wear and tear from regular use
• A Sealed and oil-filled crankcase ready to bolt on and Start pressure washing
• 7/8 Hollow shaft that fits most vertical shaft engines

The 510001 pressure washer pump is rated for a maximum pressure of 2500 PSI at a flow rate of 2.0 gallons per minute (GPM).
This OEM tch Series pump utilizes a dual axial cam bearing for better wear, friction resistance, and longer-lasting performance in harsh cleaning environments.

An integrated stainless steel unloader features an industry-leading easy-start system.

510001 OEM Technologies Pump Specifications:

Additional Notes & Service Information

The 510001 Pressure Washer pump kit is not designed for gravity-fed systems, and an on-demand water pump is always recommended to consistently supply water to the pump at 20-60 PSI of inlet pressure.

Service Note:

The "Burst Pressure" of a pressure washer pump is the highest pressure the pump produces when in a static position and when the trigger is first squeezed, giving the initial burst of pressure and does not reflect the actual operating pressure.

The accurate operating PSI of any pump would be determined by the engine’s horsepower and the size of the nozzle being used at the end of the wand, which restricts water flow and causes back pressure.

Adjusting factors such as engine RPMs, nozzle size, or engine horsepower can allow a single pump to be rated at various GPM and maximum PSI levels.

Note: If you are looking for a replacement 3 legged pump you will be looking for one of the following 3 Legged pumps.
If the Inlet and Outlet tubes on your current pump face the same direction as the spark plug of the engine on the pressure washer you will need to order SRMW2.2G26-EZ and if the Inlet and Outlet Tubes face the opposite direction as the spark plug of the engine you will need to order the SRMW2.2G26-EZSX.
