37D0018K Pilot Assembly Natural Gas Tri-Directional Flame

In stock

Part Number

37D0018K

$77.26

Part Number: 37D0018K

Compatible Brands: SIT Controls

Shipping Weight: 1 Lbs

Non Returnable

I understand this item CAN NOT be returned if the tamper evident packaging has been opened. Packaging is see-through to allow for proper inspection prior to unwrapping.

⇧ Check The Box If You Want To Proceed.

Qty

The 37D0018K pilot assembly is a natural gas pilot with a top-convertible 3-way pilot hood and a pre-installed pilot orifice. This natural gas pilot was used on Vermont Castings, Majestic, and Lexington Forge-brand fireplaces, pedestal stoves and gas log sets.

This pilot comes assembled with a thermocouple, thermo-generator, electrode with cable, and pilot tube with fixing nut. All of these components come from SIT Controls.

Pilot assembly 37D0018 and 37D0018K are the same natural gas pilot assembly with the following specifications:

SIT Controls Pilot with SIT Bracket Reference 654
23-Inch Thermo-Generator Thermopile rated for 750Mv
Pilot Tube
Electrode and Ceramic Cable
600mm Thermocouple
Natural Gas Pilot Orifice Injector from SIT Controls

Details

The 37D0018K pilot assembly services the following partial list of Majestic natural gas fireplaces:
